MD Exports LLP
EN 14399-4 10.9 HV Bolts
HEAVY HEX BOLTS STANDARD
EN 14399 – 4
| Nominal size and thread diameter d | Pitch of thread P | Thread Length b | Depth of washer face c | Transition diameter da | Diameter of unthreaded shank ds |
Diameter of washer face dw | Width across corners e | Thickness of head k |
Radius under head r | Width across flats s |
||||
| coarse pitch | Bolt ≤125 |
min. | max. | min. | min. | max. | min. | min. | min. | max. | min. | min. | max. | |
| M12 | 1.75 | 23 | 0.4 | 0.6 | 15.20 | 11.30 | 12.70 | 20.10 | 23.91 | 7.55 | 8.45 | 1.2 | 21.16 | 22.00 |
| M16 | 2.00 | 28 | 0.4 | 0.6 | 19.20 | 15.30 | 16.70 | 24.90 | 29.56 | 9.25 | 10.75 | 1.2 | 26.16 | 27.00 |
| M20 | 2.50 | 33 | 0.4 | 0.8 | 24.00 | 19.16 | 20.84 | 29.50 | 35.03 | 12.10 | 13.90 | 1.5 | 31.00 | 32.00 |
| M22 | 2.50 | 34 | 0.4 | 0.8 | 26.00 | 21.16 | 22.84 | 33.30 | 39.55 | 13.10 | 14.90 | 1.5 | 35.00 | 36.00 |
| M24 | 3.00 | 39 | 0.4 | 0.8 | 28.00 | 23.16 | 24.84 | 38.00 | 45.20 | 14.10 | 15.90 | 1.5 | 40.00 | 41.00 |
| M27 | 3.00 | 41 | 0.4 | 0.8 | 32.00 | 26.16 | 27.84 | 42.80 | 50.85 | 16.10 | 17.90 | 2.0 | 45.00 | 46.00 |
| M30 | 3.50 | 44 | 0.4 | 0.8 | 35.00 | 29.16 | 30.84 | 46.60 | 55.37 | 17.95 | 20.05 | 2.0 | 49.00 | 50.00 |
| M36 | 4.00 | 52 | 0.4 | 0.8 | 41.00 | 35.00 | 37.00 | 55.90 | 66.44 | 21.95 | 24.05 | 2.0 | 58.80 | 60.00 |
EN 14399-4 Dimensions of bolts
| Thread d | M12 | M16 | M20 | M22 | M24 | M27 | M30 | M36 | ||||||||||
| l | ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
||
| nom. | min. | max. | ||||||||||||||||
| 35 | 33.75 | 36.25 | 6.75 | 12.00 | ||||||||||||||
| 40 | 38.75 | 41.25 | 11.75 | 17.00 | 6.00 | 12.00 | ||||||||||||
| 45 | 43.75 | 46.25 | 16.75 | 22.00 | 11.00 | 17.00 | 4.50 | 12.00 | ||||||||||
| 50 | 48.75 | 51.25 | 21.75 | 27.00 | 16.00 | 22.00 | 9.50 | 17.00 | 8.50 | 16.00 | ||||||||
| 55 | 53.50 | 56.50 | 26.75 | 32.00 | 21.00 | 27.00 | 14.50 | 22.00 | 13.50 | 21.00 | ||||||||
| 60 | 58.50 | 61.50 | 31.75 | 37.00 | 26.00 | 32.00 | 19.50 | 27.00 | 18.50 | 26.00 | 12.00 | 21.00 | ||||||
| 65 | 63.50 | 66.50 | 36.75 | 42.00 | 31.00 | 37.00 | 24.50 | 32.00 | 23.50 | 31.00 | 17.00 | 26.00 | ||||||
| 70 | 68.50 | 71.50 | 41.75 | 47.00 | 36.00 | 42.00 | 29.50 | 37.00 | 28.50 | 36.00 | 22.00 | 31.00 | 20.00 | 29.00 | ||||
| 75 | 73.50 | 76.50 | 46.75 | 52.00 | 41.00 | 47.00 | 34.50 | 42.00 | 33.50 | 41.00 | 27.00 | 36.00 | 25.00 | 34.00 | 20.50 | 31.00 | ||
| 80 | 78.50 | 81.50 | 51.75 | 57.00 | 46.00 | 52.00 | 39.50 | 47.00 | 38.50 | 46.00 | 32.00 | 41.00 | 30.00 | 39.00 | 25.50 | 36.00 | ||
| 85 | 83.25 | 86.75 | 56.75 | 62.00 | 51.00 | 57.00 | 44.50 | 52.00 | 43.50 | 51.00 | 37.00 | 46.00 | 35.00 | 44.00 | 30.50 | 41.00 | 21.00 | 33.00 |
| 90 | 88.25 | 91.75 | 61.75 | 67.00 | 56.00 | 62.00 | 49.50 | 57.00 | 48.50 | 56.00 | 42.00 | 51.00 | 40.00 | 49.00 | 35.00 | 47.00 | 26.00 | 38.00 |
| 95 | 93.25 | 96.75 | 66.75 | 72.00 | 61.00 | 67.00 | 54.50 | 62.00 | 53.50 | 61.00 | 47.00 | 56.00 | 45.00 | 54.00 | 40.50 | 51.00 | 31.00 | 43.00 |
| 100 | 98.25 | 101.75 | 66.00 | 72.00 | 59.50 | 67.00 | 58.50 | 66.00 | 52.00 | 61.00 | 50.00 | 59.00 | 45.50 | 56.00 | 36.00 | 48.00 | ||
| 105 | 103.25 | 106.75 | 71.00 | 77.00 | 64.50 | 72.00 | 63.50 | 71.00 | 57.00 | 66.00 | 55.00 | 64.00 | 50.50 | 61.00 | 41.00 | 53.00 | ||
| 110 | 108.25 | 111.75 | 76.00 | 82.00 | 69.50 | 77.00 | 68.50 | 76.00 | 62.00 | 71.00 | 60.00 | 69.00 | 55.50 | 66.00 | 46.00 | 58.00 | ||
| 115 | 113.25 | 116.75 | 81.00 | 87.00 | 74.50 | 82.00 | 73.50 | 81.00 | 67.00 | 76.00 | 65.00 | 74.00 | 60.50 | 71.00 | 51.00 | 63.00 | ||
| 120 | 118.25 | 121.75 | 86.00 | 92.00 | 79.50 | 87.00 | 78.50 | 86.00 | 72.00 | 81.00 | 70.00 | 79.00 | 65.50 | 76.00 | 56.00 | 68.00 | ||
| Thread d | M12 | M16 | M20 | M22 | M24 | M27 | M30 | M36 | ||||||||||
| l | ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
ls min. |
lg max. |
||
| nom. | min. | max. | ||||||||||||||||
| 125 | 123.00 | 127.00 | 91.00 | 97.00 | 84.50 | 92.00 | 83.50 | 91.00 | 77.00 | 86.00 | 75.00 | 84.00 | 70.50 | 81.00 | 61.00 | 73.00 | ||
| 130 | 128.00 | 132.00 | 96.00 | 102.00 | 89.50 | 97.00 | 88.50 | 96.00 | 82.00 | 91.00 | 80.00 | 89.00 | 75.50 | 86.00 | 66.00 | 78.00 | ||
| 135 | 133.00 | 137.00 | 94.50 | 102.00 | 93.50 | 101.00 | 87.00 | 96.00 | 85.00 | 94.00 | 80.50 | 91.00 | 71.00 | 83.00 | ||||
| 140 | 138.00 | 142.00 | 99.50 | 107.00 | 98.50 | 106.00 | 92.00 | 101.00 | 90.00 | 99.00 | 85.50 | 96.00 | 76.00 | 88.00 | ||||
| 145 | 143.00 | 147.00 | 104.50 | 112.00 | 103.50 | 111.00 | 97.00 | 106.00 | 95.00 | 104.00 | 90.50 | 101.00 | 81.00 | 93.00 | ||||
| 150 | 148.00 | 152.00 | 109.50 | 117.00 | 108.50 | 116.00 | 102.00 | 111.00 | 100.00 | 109.00 | 95.50 | 106.00 | 86.00 | 98.00 | ||||
| 155 | 153.00 | 159.00 | 114.50 | 122.00 | 113.50 | 121.00 | 107.00 | 116.00 | 105.00 | 114.00 | 100.50 | 111.00 | 91.00 | 103.00 | ||||
| 160 | 158.00 | 164.00 | 118.50 | 126.00 | 112.00 | 121.00 | 110.00 | 119.00 | 105.50 | 116.00 | 96.00 | 108.00 | ||||||
| 165 | 163.00 | 169.00 | 123.50 | 131.00 | 117.00 | 126.00 | 115.00 | 124.00 | 110.50 | 121.00 | 101.00 | 113.00 | ||||||
| 170 | 168.00 | 174.00 | 122.00 | 131.00 | 120.00 | 129.00 | 115.50 | 126.00 | 106.00 | 118.00 | ||||||||
| 175 | 173.00 | 179.00 | 127.00 | 136.00 | 125.00 | 134.00 | 120.50 | 131.00 | 111.00 | 123.00 | ||||||||
| 180 | 178.00 | 184.00 | 132.00 | 141.00 | 130.00 | 139.00 | 125.50 | 136.00 | 116.00 | 128.00 | ||||||||
| 185 | 182.70 | 189.60 | 137.00 | 146.00 | 135.00 | 144.00 | 130.50 | 141.00 | 121.00 | 133.00 | ||||||||
| 190 | 187.70 | 194.60 | 142.00 | 151.00 | 140.00 | 149.00 | 135.50 | 146.00 | 126.00 | 138.00 | ||||||||
| 195 | 192.70 | 199.60 | 147.00 | 156.00 | 145.00 | 154.00 | 140.50 | 151.00 | 131.00 | 143.00 | ||||||||
| 200 | 197.70 | 204.60 | 150.00 | 159.00 | 147.50 | 156.00 | 136.00 | 148.00 | ||||||||||
Specification for bolts and reference standards
| Characteristic | Standard | |
| Material | Steel | |
| General Requirements | EN 14399-1 | |
| Thread | Tolerance | 6ga |
| International Standard | ISO 261, ISO 965-2 | |
| Mechanical Properties | Property Class | 10.9 |
| European Standard | EN ISO 898-1 | |
| Impact Strength | Value | Kv, min = 27 J at -20°C |
| Test Pieceb | ISO 148 | |
| Test | EN 10045-1 | |
| Tolerances | Product Grade | C except: dimensions c and r. + IT 17 Tolerance for length≥ 155mm: – 1/2 IT 17 |
| International Standard | EN ISO 4759-1 | |
| Surface Finishc | Self Colour | as processed |
| Hot Dip Galvanised | EN ISO 1461 | |
| Others | to be agreed | |
| Surface discontinuities | Limits for surface discontinuities as specified in EN26157-1. | |
| Acceptability | For acceptance procedure, see EN ISO 3269. | |
| a The tolerance class specified applies before hot-dip galvanising. Hot-dip galvanised bolts are intended for assembly with oversize tapped nuts. b The location of chappy V-notch test pieces in the bolt shall be specified in EN ISO 898-1. c Attention is drawn to the need to consider the risk of hydrogen embrittlement in the case of bolts of property class 10.9, when selecting an appropriate surface treatment process (e.g. cleaning and coating), see the relevant coating standards. d “As processed” means the normal finish resulting from manufacture with a light coating of oil. e Other coatings may be negotiated between the purchaser and the manufacturer provided they do not impair the mechanical properties or the functional characteristics. Coatings of cadmium or cadmium alloy are not permitted. |
||
