Fasteners Specification

HV 14399_4 Bolts & Nuts

Heavy Hex Bolts Standard

EN 14399 – 4

Nominal size and thread diameter d	Pitch of thread P	Thread Length b	Depth of washer face c		Transition diameter da	Diameter of unthreaded shank ds		Diameter of washer face dw	Width across corners e	Thickness of head k		Radius under head  r	Width across flats s
	coarse pitch	Bolt ≤125	min.	max.	min.	min.	max.	min.	min.	min.	max.	min.	min.	max.
M12	1.75	23	0.4	0.6	15.20	11.30	12.70	20.10	23.91	7.55	8.45	1.2	21.16	22.00
M16	2.00	28	0.4	0.6	19.20	15.30	16.70	24.90	29.56	9.25	10.75	1.2	26.16	27.00
M20	2.50	33	0.4	0.8	24.00	19.16	20.84	29.50	35.03	12.10	13.90	1.5	31.00	32.00
M22	2.50	34	0.4	0.8	26.00	21.16	22.84	33.30	39.55	13.10	14.90	1.5	35.00	36.00
M24	3.00	39	0.4	0.8	28.00	23.16	24.84	38.00	45.20	14.10	15.90	1.5	40.00	41.00
M27	3.00	41	0.4	0.8	32.00	26.16	27.84	42.80	50.85	16.10	17.90	2.0	45.00	46.00
M30	3.50	44	0.4	0.8	35.00	29.16	30.84	46.60	55.37	17.95	20.05	2.0	49.00	50.00
M36	4.00	52	0.4	0.8	41.00	35.00	37.00	55.90	66.44	21.95	24.05	2.0	58.80	60.00

EN 14399-4 Dimensions of bolts

Thread d			M12		M16		M20		M22		M24		M27		M30		M36
l			ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.
nom.	min.	max.
35	33.75	36.25	6.75	12.00
40	38.75	41.25	11.75	17.00	6.00	12.00
45	43.75	46.25	16.75	22.00	11.00	17.00	4.50	12.00
50	48.75	51.25	21.75	27.00	16.00	22.00	9.50	17.00	8.50	16.00
55	53.50	56.50	26.75	32.00	21.00	27.00	14.50	22.00	13.50	21.00
60	58.50	61.50	31.75	37.00	26.00	32.00	19.50	27.00	18.50	26.00	12.00	21.00
65	63.50	66.50	36.75	42.00	31.00	37.00	24.50	32.00	23.50	31.00	17.00	26.00
70	68.50	71.50	41.75	47.00	36.00	42.00	29.50	37.00	28.50	36.00	22.00	31.00	20.00	29.00
75	73.50	76.50	46.75	52.00	41.00	47.00	34.50	42.00	33.50	41.00	27.00	36.00	25.00	34.00	20.50	31.00
80	78.50	81.50	51.75	57.00	46.00	52.00	39.50	47.00	38.50	46.00	32.00	41.00	30.00	39.00	25.50	36.00
85	83.25	86.75	56.75	62.00	51.00	57.00	44.50	52.00	43.50	51.00	37.00	46.00	35.00	44.00	30.50	41.00	21.00	33.00
90	88.25	91.75	61.75	67.00	56.00	62.00	49.50	57.00	48.50	56.00	42.00	51.00	40.00	49.00	35.00	47.00	26.00	38.00
95	93.25	96.75	66.75	72.00	61.00	67.00	54.50	62.00	53.50	61.00	47.00	56.00	45.00	54.00	40.50	51.00	31.00	43.00
100	98.25	101.75			66.00	72.00	59.50	67.00	58.50	66.00	52.00	61.00	50.00	59.00	45.50	56.00	36.00	48.00
105	103.25	106.75			71.00	77.00	64.50	72.00	63.50	71.00	57.00	66.00	55.00	64.00	50.50	61.00	41.00	53.00
110	108.25	111.75			76.00	82.00	69.50	77.00	68.50	76.00	62.00	71.00	60.00	69.00	55.50	66.00	46.00	58.00
115	113.25	116.75			81.00	87.00	74.50	82.00	73.50	81.00	67.00	76.00	65.00	74.00	60.50	71.00	51.00	63.00
120	118.25	121.75			86.00	92.00	79.50	87.00	78.50	86.00	72.00	81.00	70.00	79.00	65.50	76.00	56.00	68.00

Thread d			M12		M16		M20		M22		M24		M27		M30		M36
l			ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.	ls min.	lg max.
nom.	min.	max.
125	123.00	127.00			91.00	97.00	84.50	92.00	83.50	91.00	77.00	86.00	75.00	84.00	70.50	81.00	61.00	73.00
130	128.00	132.00			96.00	102.00	89.50	97.00	88.50	96.00	82.00	91.00	80.00	89.00	75.50	86.00	66.00	78.00
135	133.00	137.00					94.50	102.00	93.50	101.00	87.00	96.00	85.00	94.00	80.50	91.00	71.00	83.00
140	138.00	142.00					99.50	107.00	98.50	106.00	92.00	101.00	90.00	99.00	85.50	96.00	76.00	88.00
145	143.00	147.00					104.50	112.00	103.50	111.00	97.00	106.00	95.00	104.00	90.50	101.00	81.00	93.00
150	148.00	152.00					109.50	117.00	108.50	116.00	102.00	111.00	100.00	109.00	95.50	106.00	86.00	98.00
155	153.00	159.00					114.50	122.00	113.50	121.00	107.00	116.00	105.00	114.00	100.50	111.00	91.00	103.00
160	158.00	164.00							118.50	126.00	112.00	121.00	110.00	119.00	105.50	116.00	96.00	108.00
165	163.00	169.00							123.50	131.00	117.00	126.00	115.00	124.00	110.50	121.00	101.00	113.00
170	168.00	174.00									122.00	131.00	120.00	129.00	115.50	126.00	106.00	118.00
175	173.00	179.00									127.00	136.00	125.00	134.00	120.50	131.00	111.00	123.00
180	178.00	184.00									132.00	141.00	130.00	139.00	125.50	136.00	116.00	128.00
185	182.70	189.60									137.00	146.00	135.00	144.00	130.50	141.00	121.00	133.00
190	187.70	194.60									142.00	151.00	140.00	149.00	135.50	146.00	126.00	138.00
195	192.70	199.60									147.00	156.00	145.00	154.00	140.50	151.00	131.00	143.00
200	197.70	204.60											150.00	159.00	147.50	156.00	136.00	148.00

Specification for bolts and reference standards

Characteristic		Standard
Material		Steel
General Requirements		EN 14399-1
Thread	Tolerance	6ga
	International Standard	ISO 261, ISO 965-2
Mechanical Properties	Property Class	10.9
	European Standard	EN  ISO 898-1
Impact Strength	Value	Kv, min = 27 J at -20°C
	Test Pieceb	ISO 148
	Test	EN 10045-1
Tolerances	Product Grade	C except: dimensions c and r.   + IT 17 Tolerance for length≥ 155mm:  – 1/2 IT 17
	International Standard	EN ISO 4759-1
Surface Finishc	Self Colour	as processed
	Hot Dip Galvanised	EN ISO 1461
	Others	to be agreed
Surface discontinuities		Limits for surface discontinuities as specified in EN26157-1.
Acceptability		For acceptance procedure, see EN ISO 3269.
a   The tolerance class specified applies before hot-dip galvanising. Hot-dip galvanised bolts are intended  for assembly with oversize tapped nuts. b   The location of chappy V-notch test pieces in the bolt shall be specified in EN ISO 898-1. c Attention is drawn to the need to consider the risk of hydrogen embrittlement in the case of bolts of property class 10.9, when selecting an appropriate surface treatment process (e.g. cleaning and coating), see the relevant coating standards. d   “As processed” means the normal finish resulting from manufacture with a light coating of oil. e   Other coatings may be negotiated between the purchaser and the manufacturer provided they do not impair the mechanical properties or the functional characteristics. Coatings of cadmium  or  cadmium  alloy  are  not  permitted.

Important Note

Preloaded bolted assemblies are very sensitive to differences in manufacture and lubrication. Therefore it is important that the assembly is supplied by one manufacturer who is always responsible for the function of the assembly. For the same reason, it is important that the coating of the assembly is under the control of one manufacturer. Beside the mechanical properties of the components, the functionality of the assembly requires that the specific preload can be achieved if the assembly is tightened with a suitable procedure. For this purpose a test method for the suitability of the components for preloading was created, which will demonstrate whether the function of the assembly is fulfilled.

Din 931/Din En Iso 4014 Bolts

DIN 931 / DIN EN ISO 4014

Hex head bolts

Hex Bolts Mechanical and physical properties

Mechanical or physical property									Property Class
									8.8					10.9			12.9
									≤ M16			> M16
Tensile Strength							nom.		800					1000			1200
							min.		800			830		1040			1220
Yield Strength 0.2% offset non- proportional elongation							nom.		640			640		900			1080
							min.		640			660		940			1100
Percentage elongation after fracture for machined test piece							min.		12			12		9			8
Stress Under Proof Load							nom.		580			600		830			970
Rockwell Hardness, HRC							min.		22			23		32			39
							max.		32			34		39			44
All units are displayed as newton per square millimeter (N/mm²)

Specification for bolts and reference standards

Characteristic								Standard
Material								Steel
General Requirements				International Standards				ISO 8992
Thread				Tolerance				6g
				International Standard				ISO 724, ISO 965-1
Mechanical Properties				Property Classa				d < 3mm: as agreed   3mm ≤ d ≤ 39mm: 8.8, 10.9 d > 39mm: as agreed
				International Standards				3mm ≤ d ≤ 39mm: ISO 898-1 d < 3mm and d > 39mm
Tolerances				International Standard				ISO 4759-1
Finish and/or coating								As processed
								Requirements for electroplating are covered in ISO 4042
								Requirements for non-electrolytically applied zinc flake coatings are covered in ISO 10683
								If different electroplating requirements are desired or if requirements are needed for other finishes, they should be agreed between customer and supplier.
								Limits for surface discontinuities are covered in ISO 6157-1
Acceptibility								For acceptance procedure, see ISO 3269.
a   For other property classes see ISO 898-1.

d	M33				M36			M39					M42					M45					M48		M52				M56		M60
l	ls min.			lg max.	ls min.	lg max.		ls min.			lg max.		ls min.		lg max.			ls min.		lg max.			ls min.	lg max.	ls min.		lg max.		ls min.	lg max.	ls min.		lg max.
nom.
130	34.50			52.00
140	44.50			62.00	36.00	56.00
150	54.50			72.00	46.00	66.00		40.00			60.00
160	64.50			82.00	56.00	76.00		50.00			70.00		41.50		64.00
180	84.50			102.00	76.00	96.00		70.00			90.00		61.50		84.00			55.50		78.00			47.00	72.00
200	104.50			122.00	96.00	116.00		90.00			110.00		81.50		104.00			75.50		98.00			57.00	92.00	59.00		84.00
220	111.50			129.00	103.00	123.00		97.00			117.00		88.50		111.00			82.50		105.00			74.00	99.00	66.00		91.00		55.50	83.00
240	131.50			149.00	123.00	143.00		117.00			137.00		108.50		131.00			102.50		125.00			94.00	119.00	86.00		111.00		75.50	103.00	67.50		95.00
260	151.50			169.00	143.00	163.00		137.00			157.00		128.50		151.00			122.50		145.00			114.00	139.00	106.00		131.00		95.50	123.00	87.50		115.00
280	171.50			189.00	163.00	183.00		157.00			177.00		148.50		171.00			142.50		165.00			134.00	159.00	126.00		151.00		115.50	143.00	107.50		135.00
300	191.50			209.00	183.00	203.00		177.00			197.00		168.50		191.00			162.50		185.00			154.00	179.00	146.00		171.00		135.50	163.00	127.50		155.00
320	211.50			229.00	203.00	223.00		197.00			217.00		188.50		211.00			182.50		205.00			174.00	199.00	166.00		191.00		155.50	183.00	147.50		175.00
340					223.00	243.00		217.00			237.00		208.50		231.00			202.50		225.00			194.00	219.00	186.00		211.00		175.50	203.00	167.50		195.00
360					243.00	263.00		237.00			257.00		228.50		251.00			222.50		245.00			214.00	239.00	206.00		231.00		195.50	223.00	187.50		215.00
380								257.00			277.00		248.50		271.00			242.50		265.00			234.00	259.00	226.00		251.00		215.50	243.00	207.50		235.00
400													288.50		291.00			262.50		285.00			254.00	279.00	246.00		271.00		235.50	263.00	227.50		255.00
420													298.50		311.00			282.50		305.00			274.00	299.00	266.00		291.00		255.50	283.00	247.50		275.00
440													308.50		331.00			302.50		325.00			294.00	319.00	286.00		311.00		275.50	303.00	267.50		295.00
460																							314.00	339.00	306.00		331.00		295.50	323.00	287.50		315.00
480																							334.00	359.00	326.00		351.00		315.50	343.00	307.50		335.00
500																													335.50	363.00	327.50		355.00

EN ISO 4014 (DIN931) Dimensions of bolts (concluded)

d	M10				M12			M14					M16					M18					M20		M22				M24		M27				M30
l	ls min.			lg max.	ls min.	lg max.		ls min.			lg max.		ls min.		lg max.			ls min.		lg max.			ls min.	lg max.	ls min.		lg max.		ls min.	lg max.	ls min.		lg max.		ls min.		lg max.
nom.
50	16.50			24.00	11.25	20.00
55	21.50			29.00	16.25	25.00
60	26.50			34.00	21.25	30.00		16.00			26.00
65	31.50			39.00	26.25	35.00		21.00			31.00		17.00		27.00
70	36.50			44.00	31.25	40.00		26.00			36.00		22.00		32.00			15.50		28.00
80	46.50			54.00	41.25	50.00		36.00			46.00		32.00		42.00			25.50		38.00			21.50	34.00
90	56.50			64.00	91.25	60.00		46.00			56.00		42.00		52.00			35.50		48.00			31.50	44.00	27.50		40.00		21.00	36.00
100	66.50			74.00	61.25	70.00		56.00			66.00		52.00		62.00			45.50		58.00			41.50	54.00	37.50		50.00		31.00	46.00	25.00		40.00
110					71.25	80.00		66.00			76.00		62.00		72.00			55.50		68.00			51.50	64.00	47.50		60.00		41.00	56.00	35.00		50.00		26.50		44.00
120					81.25	90.00		76.00			86.00		72.00		82.00			65.50		78.00			61.50	74.00	57.50		70.00		51.00	66.00	45.00		60.00		36.50		54.00
130								80.00			90.00		76.00		86.00			69.50		82.00			65.50	78.00	61.50		74.00		55.00	70.00	49.00		64.00		40.50		58.00
140								90.00			100.00		86.00		96.00			79.50		92.00			75.50	88.00	71.50		84.00		65.00	80.00	59.00		74.00		50.50		68.00
150													96.00		106.00			89.50		102.00			85.50	98.00	81.50		94.00		75.00	90.00	69.00		84.00		60.50		78.00
160													106.00		116.00			99.50		112.00			95.50	108.00	91.50		104.00		85.00	100.00	79.00		94.00		70.50		88.00
180																		119.50		132.00			115.50	128.00	111.50		124.00		105.00	120.00	99.00		114.00		90.50		108.00
200																							135.50	148.00	131.50		144.00		125.00	140.00	119.00		134.00		110.50		128.00
220																									138.50		151.00		132.00	147.00	126.00		141.00		117.50		135.00
240																													152.00	157.00	146.00		161.00		137.50		155.00
260																															166.00		181.00		157.50		175.00
280																																			177.50		195.00
300																																			197.50		215.00

Hex Bolts Sizes

Nominal size and threaddiameter d	Pitch of thread P		Thread Length b								Depth of washer face c						Transition Diameter da			Diameter of unthreaded shank ds				Dia. of washer face dw		Width across corners e		Thickness of head k		Radius under head  r		Width across flats    s
	coarse pitch		Bolt ≤125		Bolt 125-200			Bolt ≥200			min.			max.			max.			min.		max.		min.		min.		nom.		min.		min.		max.
M10	1.50		26		32			45			0.15			0.6			11.20			9.64		10.0		14.47		17.59		6.40		0.4		15.57		16.00
M12	1.75		30		36			49			0.15			0.6			13.70			11.57		12.00		16.47		19.85		7.50		0.6		17.57		18.00
M14	2.00		34		40			53			0.15			0.6			15.70			13.57		14.00		19.15		22.78		8.80		0.6		20.16		21.00
M16	2.00		38		44			57			0.2			0.8			17.70			15.57		16.00		22.00		26.17		10.00		0.6		23.15		24.00
M18	2.50		42		48			61			0.2			0.8			20.20			17.57		18.00		24.85		29.56		11.50		0.6		26.16		27.00
M20	2.50		46		52			65			0.2			0.8			22.40			19.48		20.00		27.70		32.95		12.50		0.8		29.16		30.00
M22	2.50		50		56			69			0.2			0.8			24.40			21.48		22.00		31.35		37.29		14.00		0.8		33.00		34.00
M24	3.00		54		60			73			0.2			0.8			26.40			23.48		24.00		33.25		39.55		15.00		0.8		35.00		36.00
M27	3.00		60		66			79			0.2			0.8			30.40			26.48		27.00		38.00		45.20		17.00		1.0		40.00		41.00
M30	3.50		66		72			85			0.2			0.8			33.40			29.48		30.00		42.75		50.85		18.70		1.0		45.00		46.00
M33	3.50		–		78			91			0.2			0.8			36.40			32.38		33.00		46.55		55.37		21.00		1.0		49.00		50.00
M36	4.00		–		84			97			0.2			0.8			39.40			35.38		36.00		51.11		60.79		22.50		1.0		53.80		55.00
M39	4.00		–		90			103			0.3			1.0			42.40			38.38		39.00		55.86		66.44		25.00		1.0		58.80		60.00
M42	4.50		–		95			109			0.3			1.0			45.60			41.38		42.00		59.95		71.30		26.00		1.2		63.10		65.00
M45	4.50		–		102			115			0.3			1.0			48.6			44.38		45.00		64.70		76.95		28.00		1.2		68.10		70.00
M48	5.00		–		108			121			0.3			1.0			52.60			47.38		48.00		69.45		82.60		30.00		1.6		73.10		75.00
M52	5.00		–		116			129			0.3			1.0			56.60			51.26		52.00		74.20		88.25		33.00		1.6		78.10		80.00
M56	5.50		–		–			137			0.3			1.0			63.00			55.26		56.00		78.66		93.56		35.00		2.0		82.80		85.00
M60	5.50		–		–			145			0.3			1.0			67.00			59.26		60.00		83.41		99.21		38.00		2.00		87.0		90.00
M64	6.00		–		–			153			0.3			1.0			71.00			63.26		64.00		88.16		104.86		40.00		2.0		92.80		96.00

Din 933/Din EN ISO 4017 Hex Set Screws

DIN 933 / DIN EN ISO 4017

Hex head screws

Nominal size and thread		Pitch of thread P		Depth of washer face c					Transition Diameter da			Dia. of washer face dw			Width across corners e	Thickness of head k	Radius under head  r	Width across flats s
diameter d		coarse pitch		min.			max.		max.			min.			min.	nom.	min.	min.		max.
M10		1.50		0.15			0.6		11.20			14.47			17.59	6.40	0.4	15.57		16.00
M12		1.75		0.15			0.6		13.70			15.47			19.95	7.50	0.6	17.57		18.00
M14		2.00		0.15			0.6		15.70			19.15			22.78	8.80	0.6	20.16		21.00
M16		2.00		0.2			0.8		17.70			22.00			26.17	10.00	0.6	23.16		24.00
M18		2.50		0.2			0.8		20.20			24.85			29.56	11.50	0.6	26.16		27.00
M20		2.50		0.2			0.8		22.40			27.70			32.95	12.50	0.8	29.16		30.00
M22		2.50		0.2			0.8		24.40			31.95			37.29	14.00	0.8	33.00		34.00
M24		3.00		0.2			0.8		25.40			33.25			39.55	15.00	0.8	35.00		36.00
M27		3.00		0.2			0.8		30.40			38.00			45.20	17.00	1.0	40.00		41.00
M30		3.50		0.2			0.8		33.40			42.75			50.85	18.70	1.0	45.00		46.00
M33		3.50		0.2			0.8		36.40			46.55			55.37	21.00	1.0	49.00		50.00
M36		4.00		0.2			0.8		39.40			51.11			60.79	22.50	1.0	53.80		55.00
M39		4.00		0.3			1.0		42.40			55.86			66.44	25.00	1.0	58.80		60.00
M42		4.50		0.3			1.0		45.60			59.95			71.30	26.00	1.2	63.10		65.00
M45		4.50		0.3			1.0		48.60			64.70			76.95	28.00	1.2	68.10		70.00
M48		5.00		0.3			1.0		52.60			69.45			82.50	30.00	1.6	73.10		75.00
M52		5.00		0.3			1.0		56.60			74.20			88.25	33.00	1.6	78.10		80.00
M56		5.50		0.3			1.0		63.00			78.66			93.56	35.00	2.0	82.80		85.00
M60		5.50		0.3			1.0		67.00			83.41			99.21	38.00	2.0	87.80		90.00
M64		6.00		0.3			1.0		71.00			88.16			104.86	40.00	2.0	92.80		95.00

Specification for bolts and reference standards

Characteristic					Standard
Material					Steel
General Requirements	International Standards				ISO 8992
Thread	Tolerance				6g
	International Standard				ISO 724, ISO 965-1
Mechanical Properties	Property Classa				d < 3mm: as agreed 3mm ≤ d ≤ 39mm: 8.8, 10.9 d > 39mm: as agreed
	International Standards				d ≤ 39mm: ISO 898-1 d < 3mm and d > 39mm: as agreed
Tolerances	International Standard				ISO 4759-1
Finish and/or coating					As processed
					Requirements for electroplating are covered in ISO 4042
					Requirements for non-electrolytically applied zinc flake coatings are covered in ISO 10683
					If different electroplating requirements are desired or if requirements are needed for other finishes, they should be agreed between customer and supplier.
					Limits for surface discontinuities are covered in ISO 6157-1
Acceptibility					For acceptance procedure, see ISO 3269.
a   For other property classes see ISO 898-1.

Mechanical and physical properties

Mechanical or physical property						Property Class
						8.8				10.9	12.9
						≤ M16		> M16
Tensile Strength			nom.			800				1000	1200
			min.			800		830		1040	1220
Yield Strength 0.2% offset non- proportional elongation			nom.			640		640		900	1080
			min.			640		660		940	1100
Percentage elongation after fracture for machined test piece			min.			12		12		9	8
Stress Under Proof Load			nom.			580		600		830	970
Rockwell Hardness, HRC			min.			22		23		32	39
			max.			32		34		39	44
All units are displayed as newton per square millimeter (N/mm²)

Standard Specification for ASTM A193

ASTM A 193

Chemical Composition for Stainless steel bolts & nuts

Grade of alloy steel for Stud-Bolts to BS 1750 , ASTM A 193 and A 320
1	SYMBOL                               B7                   B7M                  B16				B8	B8M	B8T	L7 / L7M	L43
2	Type	Ferritic	Ferritic	Austenitic	Austenitic Unstabilized	Asutenitic	Austenitic Stabilized	Ferritic	Ferritic
3	Service conditions	High Temp.	High Temp.	High Temp.	High Low. Temp.	High Low. Temp.	High Low. Temp.	Low Temp.	Low Temp.
4	Material specification
5	ASTM	A193 Grade B7	A193 Grade B7M	A193 Gr. B16	A193 Grade B8	A193 Grade B8M	A193 Grade B8T	A320 Grade L7	A320 GradeL43
	Chemical composition	%	%	%	%	%	%	%	%
6	C.	0.37—0.49	0.37—0.49	0.36—0.47	0.08 max.	0.08 max.	0.08 max.	0.38—0.48	0.38—0.43
	Mn.	0.65—1.10	0.65—1.10	0.45—0.70	2.00 max.	2.00 max.	2.00 max.	0.75—1.00	0.60—0.85
	Si.	0.15—0.35	0.15—0.35	0.15—0.35	1.00 max.	1.00 max.	1.00 max.	0.15—0.35	0.15—0.35
	P.	0.035 max.	0.035 max.	0.035 max.	0.045 max.	0.045 max.	0.045 max.	0.035 max.	0.040 max.
	S.	0.04 max.	0.04 max.	0.04 max.	0.030 max.	0.030 max.	0.030 max.	0.040 max.	0.040 max.
	Cr.	0.75—1.20	0.75—120	0.80—1.15	18.00—20.00	16.00—18.00	17.00—9.00	0.80—1.10	0.70—0.90
	Ni.	—     —	—     —	—    —	8.00—10.50	10.00—14.00	9.00—12.00	—    —	1.65—2.00
	Mo.	0.15—0.25	0.15—0.25	0.50—0.65	—    —	2.00—3.00	—     —	0.15-0.25	0.20—0.30
	V.	—     —	—    —	0.25—0.35	—    —	—    —	—     —	—    —	—     —
	Ti.	—     —	—    —	—     —	—    —	—    —	5xCMIN	—    —	—     —
	Brinell Hardness	Not applicable	max. 20 RC	Not applicable	223 B.H.N. max.	223 B.H.N. max.	223 B.H.N. max.	Not applicable	Not applicable
7	Impact Value	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	20 ft. lbf. at 1500 F	20 ft. lbf. 1500F min
8	Physicalas per ASTM A 193 & B.S. 1506-621 & B.S. 4882.
9	U.T.S.	88kg/MM2min	70.3 min.	88kg/MM2min	52.75/MM2min	52.75kg/MM2	52.75kg/MM2	88kg/MM2	88kg/MM2
	Elongation	16% min	18% min	18% min	30% min	30% min	30% min	16% min	16% min
	Yield	70.39kg/MM2	56.26 min.	73.8kg/MM2	21.1kg/MM2min	21.1kg/MM2	21.1kg/MM2	73.8kg/MM2	73.8kg/MM2
	Reduction area	50% min	50% min	50% min	50% min	50% min	50% min	50% min	50% min
	Heat treatment	Oil quenched & tempered	Oil quenched & tempered	Oil quenched & tempered	Carbide solution treated	Carbide solution treated	Carbide solution treated	Oil quenched & tempered	Oil quenched & tempered
10	Tempering temperature	11000F min 5930C	11500F min 6200C	12000F min 6500C	—      —	—     —	—    —	11000F min 5930C min	11000F min 5930C min

Chemical Composition SS 304 Grade

SS 304

Chemical Composition for Stainless steel bolts & nuts

Grade		AISI	Chemical Composition (% maxima unless stated)
			C	Si	Mn		P	S		Cr		Mo	Ni	Cu
A1		SS 202	0.12	1.0	6.5		0.20	0.15-0.35		16,0 – 19,0		0.7	5,0 – 10,0	1.75-2.25
A2		SS 304	0.08	1.0	2.0		0.05	0.03		15,0 – 20,0		0.0	8,0 – 19,0	4.0
A3		SS 321	0.08	1.0	2.0		0.05	0.03		17,0 – 19,0		0.0	9,0 – 12,0	1.0
A4		SS 316	0.08	1.0	2.0		0.05	0.03		16,0 – 18,5		2,0 – 3,0	10,0 – 15,0	4.0
C1		SS 410	0.09-0.15	1.0	1.0		0.05	0.03		11,5 – 14,0		–	1	–
C3		SS 431	0.17-0.25	1.0	1.0		0.04	0.03		16,0 – 18,0		–	1,5 – 2,5	–
C4		SS 416	0.08-0.15	1.0	1.5		0.06	0.15-0.35		12,0 – 14,0		0.6	1	–
F1		SS 430	0.12	1.0	1.0		0.04	0.03		15,0 – 18,0		0.0	1	–

Chemical Composition SS 316 Grade

SS 316 bolts & nuts

Chemical Composition for Stainless steel bolts & nuts

Grade		AISI	Chemical Composition (% maxima unless stated)
			C	Si	Mn		P	S		Cr		Mo	Ni	Cu
A1		SS 202	0.12	1.0	6.5		0.20	0.15-0.35		16,0 – 19,0		0.7	5,0 – 10,0	1.75-2.25
A2		SS 304	0.08	1.0	2.0		0.05	0.03		15,0 – 20,0		0.0	8,0 – 19,0	4.0
A3		SS 321	0.08	1.0	2.0		0.05	0.03		17,0 – 19,0		0.0	9,0 – 12,0	1.0
A4		SS 316	0.08	1.0	2.0		0.05	0.03		16,0 – 18,5		2,0 – 3,0	10,0 – 15,0	4.0
A4		316S31	0.08	1.0	2.0		0.05	0.03		16,0 – 18,5		2,0 – 3,0	10,0 – 15,0	4.0
C1		SS 410	0.09-0.15	1.0	1.0		0.05	0.03		11,5 – 14,0		–	1	–
C3		SS 431	0.17-0.25	1.0	1.0		0.04	0.03		16,0 – 18,0		–	1,5 – 2,5	–
C4		SS 416	0.08-0.15	1.0	1.5		0.06	0.15-0.35		12,0 – 14,0		0.6	1	–
F1		SS 430	0.12	1.0	1.0		0.04	0.03		15,0 – 18,0		0.0	1	–

316S31 | Steel grades

316S31

COMPARISON FOR STAINLESS STEEL INTERNATIONAL GRADES

EN	DIN	AISI	UNS	SS	AFNOR	BS
1.4005	X 12CrS13	416	S 41600	2380	Z 11 CF 13	416 S 21
1.4006	X 10Cr13	410	S 41000	2302	Z 10 C 13	410 S 21
1.4016	X 6Cr17	430	S 43000	2320	Z 8 C 17	430 S 15
1.4021	X 20 Cr 13	420	S 42000	2303	Z 20 C 13	420 S 37
1.4034	X 46Cr13			2304	Z 40 C 14	( 420 S 45 )
1.4057	X 20CrNi172	431	S 43100	2321	Z 15 CN 16.02	431 S 29
1.4104	X 12CrMoS 17	430 F	S 43020	2383	Z 13 CF 17	( 441 S 29 )
1.4112	X 90CrMoV 18	440 B	S 44003
1.4122	X 35CrMo17
1.4301	X 5CrNi1810	304	S 30400	2332	Z 6 CN 18.09	304 S 15
1.4305	X 10CrNiS189	303	S 30300	2346	Z 8 CNF 18.09	303 S 31
1.4306	X 2CrNi1911	304 L	S 30403	2352	Z 2 CN 18.10	304 S 11
1.4310	X 12CrNi177	301	S 30100	2331	Z 12 CN 18.08	301 S 22
1.4401	X 5 CrNiMo 17 12 2	316	S 31600	2347	Z 7 CND 17.12.02	316 S 31
1.4404	X 2 CrNiMo 17 13 2	316 L	S 31603	2348	Z 3 CND 18.12.02	316 S 11
1.4435	X 2 CrNiMo 18 14 3	316 L	S 31603	2353	Z 3 CND 18.14.03	316 S 11
1.4436	X 5 CrNiMo 17 13 3	316	S 31600	2343	Z 7 CND 18.12.03	316 S 31
1.4438	X 2 CrNiMo 18 16 4	317 L	S 31703	2367	Z 3 CND 19.15.04	317 S 12
1.4439	X 2 CrNiMoN 17 13	317 LNM
1.4449	X 5 CrNiMo 17 13	317	S 31700			317 S 16
1.4460	X 4 CrNiMoN 27 5 2	329	S 32900	2324	Z 5 CND 27.05 AZ
1.4462	X 2 CrNiMoN 22 5 3		S 31803	2377	(Z 5 CNDU 21.08)
1.4539	X 1 NiCrMoCuN 25 20 5		N 08904	2562	Z 1 NCDU 25.20
1.4541	X 6 CrNiTi 18 10	321	S 32100	2337	Z 6 CNT 18.10	321 S 31
1.4550	X 6 CrNiNb 18 10	347	S 34700	2338	Z 6 CNNb 18.10	347 S 31
1.4571	X 6 CrNiMoTi 17 12 2	316 TI	S 31635	2350	Z 6 CNDT 17.12	320 S 31
1.4713	X 10 CrAl 7				Z 8 CA 7
1.4724	X 10 CrAl 13				(Z 10 C 13)
1.4742	X 10 CrAl 18				Z 10 CAS 18
1.4762	X 10 CrAl 24	446	(S 44600 )	2322	Z 10 CAS 24
1.4821	X 20 CrNiSi 25 4				Z 20 CNS 25.04
1.4828	X 15 CrNiSi 20 12	309	(S 30900 )		Z 15 CNS 20.12	309 S 24
1.4841	X 15 CrNiSi 25 20	314	S 314600		Z 12 CNS 25.20	314 S 25
1.4845	X 12 CrNi 25 21	310 S	S 31008	2361	Z 12 CN 25.20	310 S 24
1.4864	X 12 NiCrSi 36 16	330	N 08330		Z 12 CNS 35.16	( 3076 NA 17 )
1.4876	X 10 NiCrAlTi 32 20	B 163			Z 8 NC 32.21	3076 NA 15 H
1.4878	X 12 CrNiTi 18 9	321	S 32100	2337	Z 6 CNT 18.12	321 S 51

Din 934/Din EN ISO 4032 Hex Head Nuts

DIN 934 / DIN EN ISO 4032

Hex head nuts

Nominal size and thread diameter d	p	da			dw	e	m		s
	(coarse pitch series)	min.		max.	min.	min.	min.	max.	min.	nom.
M10	1.50	10.00		10.80	14.60	17.77	8.04	8.40	15.73	16.00
M12	1.75	12.00		13.00	16.60	20.03	10.37	10.80	17.73	18.00
M14	2.00	14.00		15.10	19.60	23.36	12.10	12.80	20.67	21.00
M16	2.00	16.00		17.30	22.50	26.75	14.10	14.80	23.67	24.00
M18	2.50	18.00		19.50	24.90	29.56	15.10	15.80	26.16	27.00
M20	2.50	20.00		21.60	27.70	32.95	16.90	18.00	29.16	30.00
M22	2.50	22.00		23.70	31.40	37.29	18.10	19.40	33.00	34.00
M24	3.00	24.00		25.90	33.30	39.55	20.20	21.50	35.00	36.00
M27	3.00	27.00		29.10	38.00	45.20	22.50	23.80	40.00	41.00
M30	3.50	30.00		32.40	42.80	50.85	24.30	25.60	45.00	46.00
M33	3.50	33.00		35.60	46.60	55.37	27.40	28.70	49.00	50.00
M36	4.00	36.00		38.90	51.10	60.79	29.40	31.00	53.80	55.00
M39	4.00	39.00		42.10	55.90	66.44	31.80	33.40	58.80	60.00
M42	4.50	42.00		45.40	60.00	71.30	32.40	34.00	63.10	65.00
M45	4.50	45.00		48.60	64.70	76.95	34.40	36.00	68.10	70.00
M48	5.00	48.00		51.80	69.50	82.60	36.40	38.00	73.10	75.00
M52	5.00	52.00		56.20	74.20	88.25	40.40	42.00	78.10	80.00
M56	5.50	56.00		60.50	78.70	93.56	43.40	45.00	82.80	85.00
M60	5.50	60.00		64.80	83.40	99.21	46.40	48.00	87.80	90.00
M64	6.00	64.00		69.10	88.20	104.86	49.10	51.00	92.80	95.00

Specification for nuts and reference standards

Characteristic					Standard
Material					Steel
General Requirements	International Standards				ISO 8992
Thread	Tolerance				6g
	International Standard				ISO 724, ISO 965-1
Mechanical Properties	Property Classa				d < 3mm: as agreed 3mm ≤ d ≤ 39mm: 8.8, 10.9 d > 39mm: as agreed
	International Standards				d ≤ 39mm: ISO 898-1 d < 3mm and d > 39mm: as agreed
Tolerances	International Standard				ISO 4759-1
Finish and/or coating					As processed
					Requirements for electroplating are covered in ISO 4042
					Requirements for non-electrolytically applied zinc flake coatings are covered in ISO 10683
					If different electroplating requirements are desired or if requirements are needed for other finishes, they should be agreed between customer and supplier.
					Limits for surface discontinuities are covered in ISO 6157-1
Acceptibility					For acceptance procedure, see ISO 3269.
a   For other property classes see ISO 898-1.

Standard Specification for ASTM A194

ASTM A194

Chemical Composition for Alloy Steel nuts

Grade of carbon and alloy steel for nuts to BS 1750 and ASTM A 194
1	SYMBOL	2H	2HM	4	8	8M		8T	L4	7 / 7M
2	Type	Ferritic	Ferritic	Ferritic	Austenitic Unstabilized	Austenitic		Austenitic Stabilized	Ferritic	Ferritic
3	Service conditions	High Temp.	High Temp.	High Temp.	High Low. Temp.	High Low. Temp.		High Low. Temp.	Low Temp.	Low Temp.
4	Material specication ASTM	A 194 Grade 2H	A 194 Grade 2HM	A 194 Grade 4	A 194 Grade 8	A 194 Grade 8M		A 194 Grade 8T	A 194 Grade 4	A 320 Grade 7.
5	Chemical composition	%	%	%	%	%		%	%	%
6	C.	0.40 min.	0.40 min.	0.40 — 0.50	0.08 max.	0.08 max.		0.08 max.	0.40—0.50	0.37—0.49
	Mn.	1.00 max.	1.00 max.	0.70—0.90	2.00 max.	2.00 max.		0.70—0.90	0.70—0.90	0.65—1.10
	Si.	0.40 max.	0.040 max.	0.15—0.35	1.00 max.	1.00 max.		0.20—0.35	0.15—0.35	0.15—0.35
	P.	0.040 max.	0.040 max.	0.035 max.	0.045 max.	0.045 max.		0.045 max.	0.035 max.	0.040 max.
	S.	0.050 max.	0.050 max.	0.040 max.	0.030 max.	0.030 max.		0.030 max.	0.040 max.	0.040 max.
	Cr.	—      —	—      —	—      —	18.00—20.00	16.00—18.00		17.00—19.00	—      —	0.75—1.20
	Ni.	—      —	—      —	—      —	8.00—10.50	10.00—14.00		9.00—12.00	—      —	—      —
	Mo.	—      —	—      —	0.20—0.30	—      —	2.00—3.00		—      —	0.20—0.30	0.15—0.25
	V.	—      —	—      —	—      —	—      —	—      —		—      —	—      —	—      —
	Ti.	—      —	—      —	—      —	—      —	—      —		5xCMIN	—      —	—      —
	Heat Treatment	Oil quenched & tempered at 8500F 4550C min	Oil quenched & tempered at 11500F 6200C min	Oil quenched & tempered at 11000F or 5950C min	Carbide solution	Carbide solution		Carbide solution	Oil quenched & tempered at 11000F or 5950C min	Oil quenched & tempered at 11000F or 5950C min
7	Brinell Hardness	248/352	22 RC max.	248/352	126/300	126/300		126/300	248/352	248/352
8	Impact value	—      —	—      —	—      —	—      —	—      —		—      —	20 ft. lbf. at 1500F	20 ft. lbf. at 1500F

Stainless Steel A2 Grades and Classification

a2

COMPARISON FOR STAINLESS STEEL INTERNATIONAL GRADES

Grade	AISI	Chemical Composition (% maxima unless stated)
		C	Si	Mn	P	S	Cr	Mo	Ni	Cu
A1	SS 202	0.12	1.0	6.5	0.20	0.15-0.35	16,0 – 19,0	0.7	5,0 – 10,0	1.75-2.25
A2	SS 304	0.08	1.0	2.0	0.05	0.03	15,0 – 20,0	0.0	8,0 – 19,0	4.0
A3	SS 321	0.08	1.0	2.0	0.05	0.03	17,0 – 19,0	0.0	9,0 – 12,0	1.0
A4	SS 316	0.08	1.0	2.0	0.05	0.03	16,0 – 18,5	2,0 – 3,0	10,0 – 15,0	4.0
C1	SS 410	0.09-0.15	1.0	1.0	0.05	0.03	11,5 – 14,0	–	1	–
C3	SS 431	0.17-0.25	1.0	1.0	0.04	0.03	16,0 – 18,0	–	1,5 – 2,5	–
C4	SS 416	0.08-0.15	1.0	1.5	0.06	0.15-0.35	12,0 – 14,0	0.6	1	–
F1	SS 430	0.12	1.0	1.0	0.04	0.03	15,0 – 18,0	0.0	1	–

Stainless Steel A4 Grades and Classification

a4

Chemical Composition for Stainless steel bolts & nuts

Grade	AISI	Chemical Composition (% maxima unless stated)
		C	Si	Mn		P	S		Cr	Mo	Ni	Cu
A1	SS 202	0.12	1.0	6.5		0.20	0.15-0.35		16,0 – 19,0	0.7	5,0 – 10,0	1.75-2.25
A2	SS 304	0.08	1.0	2.0		0.05	0.03		15,0 – 20,0	0.0	8,0 – 19,0	4.0
A3	SS 321	0.08	1.0	2.0		0.05	0.03		17,0 – 19,0	0.0	9,0 – 12,0	1.0
A4	SS 316	0.08	1.0	2.0		0.05	0.03		16,0 – 18,5	2,0 – 3,0	10,0 – 15,0	4.0
C1	SS 410	0.09-0.15	1.0	1.0		0.05	0.03		11,5 – 14,0	–	1	–
C3	SS 431	0.17-0.25	1.0	1.0		0.04	0.03		16,0 – 18,0	–	1,5 – 2,5	–
C4	SS 416	0.08-0.15	1.0	1.5		0.06	0.15-0.35		12,0 – 14,0	0.6	1	–
F1	SS 430	0.12	1.0	1.0		0.04	0.03		15,0 – 18,0	0.0	1	–

Stainless Steel Grades Comparison Chart

Stainless Steel Comparison Chart

COMPARISON FOR STAINLESS STEEL INTERNATIONAL GRADES

EN		DIN	AISI	UNS		SS		AFNOR	BS
1.4005		X 12CrS13	416	S 41600		2380		Z 11 CF 13	416 S 21
1.4006		X 10Cr13	410	S 41000		2302		Z 10 C 13	410 S 21
1.4016		X 6Cr17	430	S 43000		2320		Z 8 C 17	430 S 15
1.4021		X 20 Cr 13	420	S 42000		2303		Z 20 C 13	420 S 37
1.4034		X 46Cr13				2304		Z 40 C 14	( 420 S 45 )
1.4057		X 20CrNi172	431	S 43100		2321		Z 15 CN 16.02	431 S 29
1.4104		X 12CrMoS 17	430 F	S 43020		2383		Z 13 CF 17	( 441 S 29 )
1.4112		X 90CrMoV 18	440 B	S 44003
1.4122		X 35CrMo17
1.4301		X 5CrNi1810	304	S 30400		2332		Z 6 CN 18.09	304 S 15
1.4305		X 10CrNiS189	303	S 30300		2346		Z 8 CNF 18.09	303 S 31
1.4306		X 2CrNi1911	304 L	S 30403		2352		Z 2 CN 18.10	304 S 11
1.4310		X 12CrNi177	301	S 30100		2331		Z 12 CN 18.08	301 S 22
1.4401		X 5 CrNiMo 17 12 2	316	S 31600		2347		Z 7 CND 17.12.02	316 S 31
1.4404		X 2 CrNiMo 17 13 2	316 L	S 31603		2348		Z 3 CND 18.12.02	316 S 11
1.4435		X 2 CrNiMo 18 14 3	316 L	S 31603		2353		Z 3 CND 18.14.03	316 S 11
1.4436		X 5 CrNiMo 17 13 3	316	S 31600		2343		Z 7 CND 18.12.03	316 S 31
1.4438		X 2 CrNiMo 18 16 4	317 L	S 31703		2367		Z 3 CND 19.15.04	317 S 12
1.4439		X 2 CrNiMoN 17 13	317 LNM
1.4449		X 5 CrNiMo 17 13	317	S 31700					317 S 16
1.4460		X 4 CrNiMoN 27 5 2	329	S 32900		2324		Z 5 CND 27.05 AZ
1.4462		X 2 CrNiMoN 22 5 3		S 31803		2377		(Z 5 CNDU 21.08)
1.4539		X 1 NiCrMoCuN 25 20 5		N 08904		2562		Z 1 NCDU 25.20
1.4541		X 6 CrNiTi 18 10	321	S 32100		2337		Z 6 CNT 18.10	321 S 31
1.4550		X 6 CrNiNb 18 10	347	S 34700		2338		Z 6 CNNb 18.10	347 S 31
1.4571		X 6 CrNiMoTi 17 12 2	316 TI	S 31635		2350		Z 6 CNDT 17.12	320 S 31
1.4713		X 10 CrAl 7						Z 8 CA 7
1.4724		X 10 CrAl 13						(Z 10 C 13)
1.4742		X 10 CrAl 18						Z 10 CAS 18
1.4762		X 10 CrAl 24	446	(S 44600 )		2322		Z 10 CAS 24
1.4821		X 20 CrNiSi 25 4						Z 20 CNS 25.04
1.4828		X 15 CrNiSi 20 12	309	(S 30900 )				Z 15 CNS 20.12	309 S 24
1.4841		X 15 CrNiSi 25 20	314	S 314600				Z 12 CNS 25.20	314 S 25
1.4845		X 12 CrNi 25 21	310 S	S 31008		2361		Z 12 CN 25.20	310 S 24
1.4864		X 12 NiCrSi 36 16	330	N 08330				Z 12 CNS 35.16	( 3076 NA 17 )
1.4876		X 10 NiCrAlTi 32 20	B 163					Z 8 NC 32.21	3076 NA 15 H
1.4878		X 12 CrNiTi 18 9	321	S 32100		2337		Z 6 CNT 18.12	321 S 51

DIN 125 A (ISO 7089) _ Washers

DIN 125

DIN 125 / DIN EN ISO 7089

A	Bolt size	B	C
21	M20	37	3
23	M22	39	3
25	M24	44	4
28	M27	50	4
31	M30	56	4
34	M33	60	5
37	M36	66	5
40	M39	72	6
43	M42	78	7
50	M48	92	8
54	M52	98	8

DIN 912 / DIN EN ISO 4762 Socket Cap Screws

DIN 912 / DIN EN ISO 4762

Hex head Screws

Nominal size and thread diameter d	Pitch of thread P	Thread length b	Head diameter dk		Transition diameter da	Diameter of unthreaded shank ds		Hex socket width across corners e	Thickness of head k		Radius under head r	Hex socket width across flats s			Hex socket depth t	w
	coarse pitch	max.	min.	max.	max.	min.	max.	min.	min.	max.	nom.	min.	max.	nom.	min.	min.
M10	1.50	32	15.73	16.00	11.20	9.78	10.00	9.15	9.64	10.00	0.4	8.03	8.18	8.00	5.0	4.0
M12	1.75	36	17.73	18.00	13.70	11.73	12.00	11.43	11.57	12.00	0.6	10.03	10.18	10.00	6.0	4.8
M14	2.00	40	20.67	21.00	15.70	13.73	14.00	13.73	13.57	14.00	0.6	12.03	12.21	12.00	7.0	5.8
M16	2.00	44	23.67	24.00	17.70	15.73	16.00	15.73	15.57	16.00	0.6	14.03	14.21	14.00	8.0	6.8
M18	2.50	48	26.67	27.00	20.20	17.73	18.00	17.73	17.57	18.00	0.6	14.03	14.21	14.00	9.0	7.8
M20	2.50	52	29.67	30.00	22.40	19.67	20.00	19.44	19.48	20.00	0.8	17.05	17.23	17.00	10.0	8.6
M22	2.50	56	32.61	33.00	24.40	21.67	22.00	19.44	21.48	22.00	0.8	17.05	17.23	17.00	11.0	9.4
M24	3.00	60	35.61	36.00	26.40	23.67	24.00	21.73	23.48	24.00	0.8	19.07	19.28	19.00	12.0	10.4
M27	3.00	66	39.61	40.00	30.40	26.67	27.00	21.73	26.48	27.00	1.0	19.07	19.28	19.00	13.5	11.9
M30	3.50	72	44.61	45.00	33.40	29.67	30.00	25.15	29.48	30.00	1.0	22.07	22.28	22.00	15.5	13.1
M33	3.50	78	49.61	50.00	36.40	32.61	33.00	27.43	32.38	33.00	1.0	24.07	24.28	24.00	18.0	13.5
M36	4.00	84	53.54	54.00	39.40	35.61	36.00	30.85	35.38	36.00	1.0	27.07	27.28	27.00	19.0	15.3
M42	4.50	95	62.54	63.00	45.50	41.61	42.00	36.57	41.38	42.00	1.2	32.08	32.33	32.00	24.0	16.3
M48	5.00	108	71.54	72.00	52.60	47.61	48.00	41.13	47.38	48.00	1.6	36.08	36.33	36.00	28.0	17.5
M56	5.50	124	83.46	84.00	63.00	55.54	56.00	46.83	56.26	56.00	2.0	41.08	41.33	41.00	34.0	19.0
M64	6.00	140	95.46	96.00	71.00	63.54	64.00	52.53	63.26	64.00	2.0	46.08	46.33	46.00	38.0	22.0
M72	6.00	156	107.46	108.00	79.00	71.54	72.00	62.81	71.26	72.00	2.0	55.10	55.10	55.00	43.0	25.0
M80	6.00	172	119.46	120.00	87.00	79.54	80.00	74.21	79.26	80.00	2.0	65.10	65.40	65.00	48.0	27.0
M90	6.00	192	134.37	135.00	97.00	89.46	90.00	85.61	89.13	90.00	2.5	75.10	75.40	75.00	54.0	32.0
M100	6.00	212	149.37	150.63	107.00	99.46	100.00	97.04	99.13	100.00	2.5	85.12	85.47	85.00	60.0	34.0

DIN 912 Dimensions of Socket Head Screws (concluded)

d	M10			M12			M14				M16		M18				M20				M22				M24		M27		M30
l	ls min.		lg max.	ls min.	lg max.		ls min.		lg max.		ls min.	lg max.	ls min.	lg max.			ls min.		lg max.		ls min.		lg max.		ls min.	lg max.	ls min.	lg max.	ls min.		lg max.
nom.
25	–		4.50	–	5.25		–		6.00		–	6.00
30	–		4.50	–	5.25		–		6.00		–	6.00	–	7.50			–		7.50
35	–		4.50	–	5.25		–		6.00		–	6.00	–	7.50			–		7.50		–		7.50
40	–		4.50	–	5.25		–		6.00		–	6.00	–	7.50			–		7.50		–		7.50		–	9.00
45	5.50		13.00	–	5.25		–		6.00		–	6.00	–	7.50			–		7.50		–		7.50		–	9.00	–	9.00	–		10.50
50	10.50		18.00	–	5.25		–		6.00		–	6.00	–	7.50			–		7.50		–		7.50		–	9.00	–	9.00	–		10.50
55	15.50		23.00	10.25	19.00		–		6.00		–	6.00	–	7.50			–		7.50		–		7.50		–	9.00	–	9.00	–		10.50
60	20.50		28.00	15.25	24.00		10.00		20.00		–	6.00	–	7.50			–		7.50		–		7.50		–	9.00	–	9.00	–		10.50
65	25.50		33.00	20.25	29.00		15.00		25.00		11.00	21.00	–	7.50			–		7.50		–		7.50		–	9.00	–	9.00	–		10.50
70	30.50		38.00	25.25	34.00		20.00		30.00		16.00	26.00	9.50	22.00			–		7.50		–		7.50		–	9.00	–	9.00	–		10.50
80	40.50		48.00	35.25	44.00		30.00		40.00		26.00	36.00	19.50	32.00			15.50		28.00		11.50		24.00		–	9.00	–	9.00	–		10.50
90	50.50		58.00	45.25	54.00		40.00		50.00		36.00	46.00	29.50	42.00			25.50		38.00		21.50		34.00		15.00	30.00	–	9.00	–		10.50
100	60.50		68.00	55.25	64.00		50.00		60.00		46.00	56.00	39.50	52.00			35.50		48.00		31.50		44.00		25.00	40.00	19.00	34.00	–		10.50
110				65.25	74.00		60.00		70.00		56.00	66.00	49.50	62.00			45.50		58.00		41.50		54.00		35.00	50.00	29.00	44.00	20.50		38.00
120				75.25	84.00		70.00		80.00		66.00	76.00	59.50	72.00			55.50		68.00		51.50		64.00		45.00	60.00	39.00	54.00	30.50		48.00
130							80.00		90.00		76.00	86.00	69.50	82.00			65.50		78.00		61.50		74.00		55.00	70.00	49.00	64.00	40.50		58.00
140							90.00		100.00		86.00	96.00	79.50	92.00			75.50		88.00		71.50		84.00		65.00	80.00	59.00	74.00	50.50		68.00
150											96.00	106.00	89.50	102.00			85.50		98.00		81.50		94.00		75.00	90.00	69.00	84.00	60.50		78.00
160											106.00	116.00	99.50	112.00			95.50		108.00		91.50		104.00		85.00	100.00	79.00	94.00	70.50		88.00
180													119.50	132.00			115.50		128.00		111.50		124.00		105.00	120.00	99.00	114.00	90.50		108.00
200																	135.50		148.00		131.50		144.00		125.00	140.00	119.00	134.00	110.50		128.00

d	M33			M36			M42				M48		M56				M64				M72				M80		M90		M100
l	ls min.		lg max.	ls min.	lg max.		ls min.		lg max.		ls min.	lg max.	ls min.	lg max.			ls min.		lg max.		ls min.		lg max.		ls min.	lg max.	ls min.	lg max.	ls min.		lg max.
nom.
50	–		10.50
55	–		10.50	–	12.00
60	–		10.50	–	12.00		–		13.50
65	–		10.50	–	12.00		–		13.50
70	–		10.50	–	12.00		–		13.50		–	15.00
80	–		10.50	–	12.00		–		13.50		–	15.00	–	16.50
90	–		10.50	–	12.00		–		13.50		–	15.00	–	16.50			–		18.00
100	–		10.50	–	12.00		–		13.50		–	15.00	–	16.50			–		18.00		–		18.00
110	14.50		32.00	–	12.00		–		13.50		–	15.00	–	16.50			–		18.00		–		18.00
120	24.50		42.00	16.00	36.00		–		13.50		–	15.00	–	16.50			–		18.00		–		18.00		–	18.00
130	34.50		52.00	26.00	46.00		–		13.50		–	15.00	–	16.50			–		18.00		–		18.00		–	18.00
140	44.50		62.00	36.00	56.00		21.50		44.00		–	15.00	–	16.50			–		18.00		–		18.00		–	18.00	–	18.00
150	54.50		72.00	46.00	66.00		31.50		54.00		–	15.00	–	16.50			–		18.00		–		18.00		–	18.00	–	18.00	–		18.00
160	64.50		82.00	56.00	76.00		41.50		64.00		27.00	52.00	–	16.50			–		18.00		–		18.00		–	18.00	–	18.00	–		18.00
180	84.50		102.00	76.00	96.00		61.50		84.00		47.00	72.00	56.00	56.00			–		18.00		–		18.00		–	18.00	–	18.00	–		18.00
200	104.50		122.00	96.00	116.00		81.50		104.00		67.00	92.00	48.50	76.00			30.00		60.00		–		18.00		–	18.00	–	18.00	–		18.00
220	124.50		142.00	116.00	136.00		101.50		124.00		87.00	112.00	68.50	96.00			50.00		80.00		34.00		64.00		–	18.00	–	18.00	–		18.00
240	144.50		162.00	136.00	156.00		121.50		144.00		107.00	132.00	88.50	116.00			70.00		100.00		54.00		84.00		38.00	68.00	–	18.00	–		18.00
260	164.50		182.00	156.00	176.00		141.50		164.00		127.00	152.00	108.50	136.00			90.00		120.00		74.00		104.00		58.00	88.00	38.00	68.00	–		18.00
280	184.50		202.00	176.00	196.00		161.50		184.00		147.00	172.00	128.50	156.00			110.00		140.00		94.00		124.00		78.00	108.00	58.00	88.00	38.00		68.00
300	204.50		222.00	196.00	216.00		181.50		204.00		167.00	192.00	148.50	176.00			130.00		160.00		114.00		144.00		98.00	128.00	78.00	108.00	58.00		88.00

Specification for bolts and reference standards

Characteristic							Standard
Material							Steel
General Requirements							As specified in DIN 267 Part 1.
Thread			Tolerance				5g6g for property class 12.9; 6ga for other property classes.
			Standard				ISO 261, ISO 965.
Mechanical Properties			Property Class (material)				d ≤ M39b: 8.8; 10.9; 12.9 d > M39: as agreed
			Standard				DIN ISO 898 Part 1
Tolerances on dimensions and form			Product Grade				A
			Standard				ISO 4759/1/DIN ISO 4759 Part 1
Surface finish							Black oxide (thermal or chemical)
							DIN 267 Part 2 shall apply with regard to surface roughness.
							DIN 267 Part 19 shall apply with regard to the permissable surface defects.
							DIN 267 Part 9 shall apply with regard to electroplating.
							If different electroplating or other surface protection is desired, this shall be agreed upn at the time of ordering
Acceptable inspection							DIN 267 Part 5 shall apply with regard to acceptance testing.
a   Only for screws without surface protection, 6g makes it possible for normal coating thicknesses to be applied in accordance with DIN 267 Part 9 but the reference line shall not be exceeded. Depending on the coating thickness required, a larger fundamental deviation shall be selected that for the g position. A larger fundamental deviation may impair the stripping strength of the screw/nut connection. b  In ISO 4762, only up to M36 or below.

High Tensile HV Bolts & Nuts | HDG | Hot Dip Galvanised Bolts | DIN 6914 | DIN 6915

ATR Specification sheet

Low carbon all threaded rod, Zinc plated

Diameter	Nominal Size	D ( Major Diameter )
		Max.	Min.
1/4″‐20	0.2500	0.2489	0.2408
1/4″‐28	0.2500	0.2490	0.2425
5/16″‐18	0.3125	0.3113	0.3026
5/16″‐24	0.3125	0.3114	0.3042
3/8″‐16	0.3750	0.3737	0.3643
3/8″‐24	0.3750	0.3739	0.3667
7/16″‐14	0.4375	0.4361	0.4258
7/16″‐20	0.4375	0.4362	0.4281
1/2″‐13	0.5000	0.4985	0.4876
1/2″‐20	0.5000	0.4987	0.4906
9/16″‐12	0.5625	0.5609	0.5495
9/16″‐18	0.5625	0.5611	0.5524
5/8″‐11	0.6250	0.6233	0.6113
5/8″‐18	0.6250	0.6236	0.6149
3/4″‐10	0.7500	0.7482	0.7353
3/4″‐16	0.7500	0.7485	0.7391
7/8″‐9	0.8750	0.8731	0.8592
7/8″‐14	0.8750	0.8734	0.8631
1″‐8	1.0000	0.9980	0.9830
1″‐12	1.0000	0.9982	0.9868
1.1/8″‐7	1.1250	1.1228	1.0640
1.1/8″‐12	1.1250	1.1229	1.1118
1.1/4″‐7	1.2500	1.2478	1.2314
1.1/4″‐12	1.2500	1.2482	1.2368
1.3/8″‐6	1.3750	1.3726	1.3544
1.3/8″‐12	1.3750	1.3731	1.3617
1.1/2″‐6	1.5000	1.4976	1.4794
1.1/2″‐12	1.5000	1.4981	1.4867
1.3/4″‐5	1.7500	1.7473	1.7268
2″‐4.5	2.0000	1.9971	1.9751
(L) Measure the length end to end using a tolerance of +/‐ 1/2″

U_Bolts Datasheets | Big Size Bolts Nuts

U BOLT DATA SHEET



Pipe Size		Description	Thread Size	Centres (N)	(M)	Thread Length (K)	S (MAX)	Max. Load up to 3400C	Item Weight	Part No.
Nominal Size	Outside Diameter (A)
NB	mm			mm	mm	mm	mm	kN	kg	Carbon Steel	Stainless Steel
15	21.3	15NB U-Bolt Clamp	M8	30	50	25	7	0.68	0.07	181001	181030
20	26.7	20NB U-Bolt Clamp	M8	35	60	25	10	0.54	0.08	181002	181031
25	33.4	25NB U-Bolt Clamp	M8	45	65	25	10	0.43	0.08	181003	181032
32	42.2	32NB U-Bolt Clamp	M8	55	75	25	10	0.34	0.09	181004	181033
40	48.3	40NB U-Bolt Clamp	M10	60	90	35	16	0.60	0.18	181005	181034
50	60.3	50NB U-Bolt Clamp	M10	75	100	35	16	0.48	0.20	181006	181035
65	76.1	65NB U-Bolt Clamp	M12	90	130	45	19	0.70	0.34	181007	181036
80	88.9	80NB U-Bolt Clamp	M16	105	150	50	19	1.50	0.70	181008	181037
100	114.3	100NB U-Bolt Clamp	M16	135	175	50	19	1.17	0.81	181009	181038
125	141.3	125NB U-Bolt Clamp	M16	160	200	50	19	0.94	0.91	181010	181039
150	168.3	150NB U-Bolt Clamp	M20	190	235	55	19	1.52	1.69	181011	181040
175	193.7	175NB U-Bolt Clamp	M20	215	270	55	19	1.32	1.85	181012	181041
200	219.1	200NB U-Bolt Clamp	M20	245	295	55	19	1.17	2.07	181013	181042
225	244.5	225NB U-Bolt Clamp	M20	266	315	60	19	1.05	2.18	181014	181043
250	273.0	250NB U-Bolt Clamp	M20	300	350	60	22	0.94	2.43	181015	181044
300	323.9	300NB U-Bolt Clamp	M20	350	400	60	22	0.79	2.75	181016	181045
350	355.6	350NB U-Bolt Clamp	M24	385	440	65	22	1.25	4.38	181017	181046
400	406.4	400NB U-Bolt Clamp	M24	435	500	65	22	1.09	4.92	181018	181047
450	457.2	450NB U-Bolt Clamp	M24	485	540	70	22	0.97	5.32	181019	181048
500	508.0	500NB U-Bolt Clamp	M24	540	600	70	22	0.87	5.87	181020	181049
550	559.0	550NB U-Bolt Clamp	M24	584	650	70	22	0.73	6.34	181021	181050
600	609.6	600NB U-Bolt Clamp	M24	640	700	70	22	0.67	6.81	181022	181051
650	660.4	650NB U-Bolt Clamp	M24	690	740	70	24	0.62	7.20	181023	181052
700	711.2	700NB U-Bolt Clamp	M30	750	810	80	24	1.18	12.49	181024	181053
750	762	750NB U-Bolt Clamp	M30	800	860	80	24	1.10	13.22	181025	181054
800	812.8	800NB U-Bolt Clamp	M30	850	910	80	24	1.04	13.95	181026	181055
850	863.6	850NB U-Bolt Clamp	M30	900	960	80	24	0.98	14.68	181027	181056
900	914.4	900NB U-Bolt Clamp	M30	950	1010	80	24	0.93	15.41	181028	181057
1000	1016.0	1000NB U-Bolt Clamp	M30	1050	1060	80	24	1.56	24.94	181029	181058

Shank | Clamping | Threading | Tightening Length HV Hot Dip Galvanised Bolt & Nut

HV-bolts Shank & Thread Length

M30 to M64

L		Shank lengths ls and lg
		M30					M36			M39						M42						M45						M48							M56			M64
Nominal Size		ls min.			lg max.		ls min.		lg max.	ls min.			lg max.			ls min.			lg max.			ls min.			lg max.			ls min.				lg max.			ls min.		lg max.	ls min.				lg max.
70		15,5			26
80		25,5			36		16		28
90		35,5			46		26		38
100		45,5			56		36		48
110		55,5			66		46		58	30			42
120		65,5			76		56		68	40			52			32,5			46			30,5			44
130		75,5			86		66		78	50			62			42,5			56			40,5			54			33				48
140		85,5			96		76		88	60			72			52,5			66			50,5			64			43				58			33,5		50
150		95,5			106		86		98	70			82			62,5			76			60,5			74			53				68			43,5		60	32				50
160		105,5			116		96		108	80			92			72,5			86			70,5			84			63				78			53,5		70	42				60
170		115,5			126		106		118	90			102			82,5			96			80,5			94			73				88			63,5		80	52				70
180		125,5			136		116		128	100			112			92,5			106			90,5			104			83				98			73,5		90	62				80
190		135,5			146		126		138	110			122			102,5			116			100,5			114			93				108			83,5		100	72				90
200		145,5			156		136		148	120			132			112,5			126			110,5			124			103				118			93,5		110	82				100
210		155,5			166		146		158	130			142			122,5			136			120,5			134			113				128			103,5		120	92				110
220		165,5			176		156		168	140			152			132,5			146			130,5			144			123				138			113,5		130	102				120
230		175,5			186		166		178	150			162			142,5			156			140,5			154			133				148			123,5		140	112				130
240		185,5			196		176		188	160			172			152,5			166			150,5			164			143				158			133,5		150	122				140
250		195,5			206		186		198	170			182			162,5			176			160,5			174			153				168			143,5		160	132				150
260		205,5			216		196		208	180			192			172,5			186			170,5			184			163				178			153,5		170	142				160
270		215,5			226		206		218	190			202			182,5			196			180,5			194			173				188			163,5		180	152				170
280		225,5			236		216		228	200			212			192,5			206			190,5			204			183				198			173,5		190	162				180
290		235,5			246		226		238	210			222			202,5			216			200,5			214			193				208			183,5		200	172				190
300		245,5			256		236		248	220			232			212,5			226			210,5			224			203				218			193,5		210	182				200
310		255,5			266		246		258	230			242			222,5			236			220,5			234			213				228			203,5		220	192				210
320		265,5			276		256		268	240			252			232,5			246			230,5			244			223				238			213,5		230	202				220
330		275,5			286		266		278	250			262			242,5			256			240,5			254			233				248			223,5		240	212				230
340		285,5			296		276		288	260			272			252,5			266			250,5			264			243				258			233,5		250	222				240
350		295,5			306		286		298	270			282			262,5			276			260,5			274			253				268			243,5		260	232				250
360		305,5			316		296		308	280			292			272,5			286			270,5			284			263				278			253,5		270	242				260
370		315,5			326		306		318	290			302			282,5			296			280,5			294			273				288			263,5		280	252				270
380		325,5			336		316		328	300			312			292,5			306			290,5			304			283				298			273,5		290	262				280
390		335,5			346		326		338	310			322			302,5			316			300,5			314			293				308			283,5		300	272				290
400		345,5			356		336		348	320			332			312,5			326			310,5			324			303				318			293,5		310	282				300
410		355,5			366		346		358	330			342			322,5			336			320,5			334			313				328			303,5		320	292				310
420		365,5			376		356		368	340			352			332,5			346			330,5			344			323				338			313,5		330	302				320
430		375,5			386		366		378	350			362			342,5			356			340,5			354			333				348			323,5		340	312				330
440		385,5			396		376		388	360			372			352,5			366			350,5			364			343				358			333,5		350	322				340
450		395,5			406		386		398	370			382			362,5			376			360,5			374			353				368			343,5		360	332				350
460		405,5			416		396		408	380			392			372,5			386			370,5			384			363				378			353,5		370	342				360
470		415,5			426		406		418	390			402			382,5			396			380,5			394			373				388			363,5		380	352				370
480		425,5			436		416		428	400			412			392,5			406			390,5			404			383				398			373,5		390	362				380
490		435,5			446		426		438	410			422			402,5			416			400,5			414			393				408			383,5		400	372				390
500		445,5			456		436		448	420			432			412,5			426			410,5			424			403				418			393,5		410	382				400

DAST Guidelines/Dimensions 021 Bolts & Nut

Dimensions as per DASt Guidelines 021

Geometry of HV-bolts with associated HV-nuts and HV-washers

Bolt dimensions* (in millimetres)
Nominal size					M30		M36			M391)		M42			M451)				M48				M56				M64
p2)					3,5		4			4		4,5			4,5				5				5,5				6
	min.				0,4		0,4			0,5		0,5			0,5				0,5				0,5				0,5
	max.				0,8		0,8			1		1			1				1				1				1
da	max.				35		41			45		48			52				55				64,2				73,2
ds	nom.				30		36			39		42			45				48				56				64
	min.				29,16		35			38		41			44				47				54,8				62,8
	max.				30,84		37			40		43			46				49				57,2				65,2
dw	min.				46,6		559			60		647			6,945				742				83,4				92,9
e	min.				55,37		66,44			71,3		76,95			82,6				88,25				99,2				11,05
k	nom.				19		23			25		26			28				30				35				40
	min.				17,95		21,95			23,95		24,95			26,95				28,95				33,75				38,75
	max.				20,05		24,05			26,05		27,05			29,05				31,05				36,25				41,25
kw	min.				12,56		15,36			16,76		17,46			18,86				20,26				23,63				27,13
r	min.				2		2			2,5		2,5			3				3				3,5				4
s	max.				50		60			65		70			75				80				90				100
	min.				49		58,8			63,1		68,1			73,1				78,1				87,8				97,8

Nut dimensions* (in millimetres)

p2)					3,5		4			4		4,5			4,5				5				5,5				6
da	max.				32,4		38,9			–		–			–				–				–				–
	min.				30		36			–		–			–				–				–				–
dw	min.				46,6		55,9			60		64,7			69,5				74,2				83,4				92,9
e	min.				55,37		66,44			71,3		76,95			82,6				88,25				99,2				110,5
m	nom. = max.				24		29			31		34			36				38				45				51
	min.				22,7		27,7			29,4		32,4			34,4				36,4				43,4				49,1
mw	min.				18,16		22,16			23,5		25,9			27,5				291				34,,7				39,3
s	max.				50		60			65		70			75				80				90				100
	min.				49		58,8			63,1		68,1			73,1				78,1				87,8				97,8

Washer dimensions* (in millimetres)

d1	min. = nom.				31		37			40,4		43,4			46,4				49,4				58				66
	max.				31,62		37,62			41,02		44,02			47,02				50,02				58,74				66,74
d2	min.				54,8		64,8			70,8		76,8			83,6				90,6				103,6				113,6
	max. = nom.				56		66			72		78			85				9				105				115
h	Nominal size				5		6			6		8			8				8				10				10
	min.				4,4		5,4			5,4		6,8			6,8				6,8				8,8				8,8
	max.				5,6		6,4			6,4		9,2			9,2				9,2				11,2				11,2
c	min. = nom.				2,5		2,5			3		3			3,4				3,4				4				4,5
	max.				3		3			3,5		3,5			4				4				4.5				5
e	Nominal size = min.				1		1,25			1,25		1,5			1,5				1,5				2				2
	max.				2		2,5			2,5		3			3				3				4				4

*The dimensions before galvanization are for hot dip galvanized bolts, nuts and washers
1) Special sizes; customized production
2) P = Thread pitch (standard thread)
3) d_w,max. = s_act.

HV Clamping Length Dast Guideline 021 Bolt & Nut

Clamping Lengths

Clamping pattern with large width across flats

Clamping length I

Clamping length lk

M301)

M361)

M39

M42

M45

M48

M56

M64

70

24 – 29

80

34 – 39

26 – 31

90

44 – 49

36 – 41

100

54 – 59

46 – 51

110

64 – 69

56 – 61

48 – 58

120

74 – 79

66 – 71

58 – 68

50 – 61

48 – 58

130

84 – 89

76 – 81

68 – 78

60 – 71

58 – 68

54 – 67

140

94 – 99

86 – 91

78 – 88

70 – 81

68 – 78

64 – 77

54 – 65,1

150

104 – 109

96 – 101

88 – 98

80 – 91

78 – 88

74 – 87

64 – 75,1

56 – 69

160

114 – 119

106 – 111

98 – 108

90 – 101

88 – 98

84 – 97

74 – 85,1

66 – 79

170

124 – 129

116 – 121

108 – 118

100 – 111

98 – 108

94 – 107

84 – 95

76 – 89

180

134 – 139

126 – 131

118 – 128

110 – 121

108 – 118

104 – 117

94 – 105

86 – 99

190

144 – 149

136 – 141

128 – 138

120 – 131

118 – 128

114 – 126

104 – 115

96 – 108

200

154 – 159

146 – 151

138 – 148

130 – 141

128 – 138

124 – 136

114 – 125

106 – 118

210

164 – 169

156 – 161

148 – 158

140 – 151

138 – 148

134 – 146

124 – 135

116 – 128

220

174 – 179

166 – 171

158 – 168

150 – 161

148 – 158

144 – 156

134 – 145

126 – 138

230

184 – 189

176 – 181

168 – 178

160 – 171

158 – 168

154 – 166

144 – 155

136 – 148

240

194 – 199

186 – 191

178 – 188

170 – 181

168 – 178

164 – 176

154 – 165

146 – 158

250

204 – 209

196 – 201

188 – 198

180 – 191

178 – 188

174 – 186

164 – 175

156 – 168

260

214 – 219

206 – 211

198 – 208

190 – 201

188 – 198

184 – 196

174 – 185

166 – 178

270

224 – 229

216 – 221

208 – 218

200 – 211

198 – 208

194 – 206

184 – 195

176 – 188

280

234 – 239

226 – 231

218 – 228

210 – 221

208 – 218

204 – 216

194 – 205

186 – 198

290

244 – 249

236 – 241

228 – 238

220 – 231

218 – 228

214 – 226

204 – 215

196 – 208

300

254  – 259

246 – 251

238 – 248

230 – 241

228 – 238

224 – 236

214 – 225

206 – 218

310

264 – 269

256 – 261

248 – 258

240 – 251

238 – 248

234 – 246

224 – 235

216 – 228

320

274 – 279

266 – 271

258 – 268

250 – 260

248 – 258

244 – 256

234 – 244

226 – 238

330

284 – 289

276 – 281

268 – 278

260 – 270

258 – 268

254 – 266

244 – 254

236 – 248

340

294 – 299

286 – 291

278 – 288

270 – 280

268 – 278

264 – 276

254 – 264

246 – 258

350

304 – 309

296 – 301

288 – 298

280 – 290

278 – 288

274 – 286

264 – 274

256 – 268

360

314 – 319

306 – 311

298 – 308

290 – 300

288 – 298

284 – 296

274 – 284

266 – 278

370

324 – 329

316 – 321

308 – 318

300 – 310

298 – 308

294 – 306

284 – 294

276 – 288

380

334 – 339

326 – 331

318 – 328

310 – 320

308 – 318

304 – 316

294 – 304

286 – 298

390

344 – 349

336 – 341

328 – 338

320 – 330

318 – 328

314 – 326

304 – 314

296 – 308

400

354 – 359

346 – 351

338 – 348

330 – 340

328 – 338

324 – 336

314 – 324

306 – 318

410

364 – 369

356 – 361

348 – 358

340 – 350

338 – 348

334 – 345

324 – 334

316 – 327

420

374 – 379

366 – 371

358 – 368

350 – 360

348 – 358

344 – 355

334 – 344

326 – 337

430

384 – 389

376 – 381

368 – 378

360 – 370

358 – 368

354 – 365

344 – 354

336 – 347

440

394 – 399

386 – 391

378 – 388

370 – 380

368 – 378

364 – 375

354 – 364

346 – 357

450

404 – 409

396 – 401

388 – 398

380 – 390

378 – 388

374 – 385

364 – 374

356 – 367

460

414 – 419

406 – 411

398 – 408

390 – 400

388 – 398

384 – 395

374 – 384

366 – 377

470

424 – 429

416 – 421

408 – 418

400 – 410

398 – 408

394 – 405

384 – 394

376 – 387

480

434 – 439

426 – 431

418 – 428

410 – 420

408 – 418

404 – 415

394 – 404

386 – 397

490

444 – 449

436 – 441

428 – 438

420 – 430

418 – 428

414 – 425

404 – 414

396 – 407

500

454 – 459

446 – 451

438 – 448

430 – 440

428 – 438

424 – 435

414 – 424

406 – 417

1) Unlike in DIN EN 14399-4, the clamping lengths åt was converted to lk for sizes M30 and M36 to obtain a uniform clamping length table in accordance with DASt guideline 021.

Key Tags: Clamping length Bolt & nuts | Clamping Length Dast Guideline 021 Bolt & Nut | DASt guideline 021 bolt & nut | Dast Guideline 021 Bolt & Nut Weight Chart

HV Bolts & Nuts Weight Count Chart _ Dast Guideline 021, Bigger & Large Diameter

HV-BOLTS SETS WEights in kg/100 pcs

Weights of HV Bolts Sets

Thread, d								M30		M36					M39					M42						M45					M48					M56				M64
Nominal length, l								Weight* in kg/100 pcs., with 7.85 kg/dm3
70								64,4
80								69,9		110,5
90								75,5		118,49
100								81,0		126,48
110								86,6		134,5					161,1
120								92,1		142,5					170,5					200,6						238,6
130								97,7		150,5					179,9					211,5						251,1					294,7
140								103,2		158,4					189,3					222,4						263,6					308,9					431,4
150								108,8		166,4					198,6					233,3						276,1					323,1					450,7				608,0
160								114,3		174,4					208,0					244,1						288,6					337,3					470,1				633,2
170								119,9		182,4					217,4					255,0						301,1					351,5					489,4				658,5
180								125,4		190,4					226,8					265,9						313,5					365,8					508,7				683,7
190								131,0		198,4					236,2					276,8						326,0					380,0					528,1				709,0
200								136,5		206,4					245,5					287,6						338,5					394,2					547,4				734,2
210								142,1		214,4					254,9					298,5						351,0					408,4					566,8				759,5
220								147,6		222,4					264,3					309,4						363,5					422,6					586,1				784,7
230								153,2		230,4					273,7					320,3						376,0					436,8					605,4				810,0
240								158,7		238,3					283,0					331,1						388,5					451,0					624,8				835,3
250								164,3		246,3					292,4					342,0						400,9					465,2					644,1				860,5
260								169,8		254,3					301,8					352,9						413,4					479,4					663,4				885,8
270								175,4		262,3					311,2					363,8						425,9					493,6					682,8				911,0
280								180,9		270,3					320,6					374,6						438,4					507,8					702,1				936,3
290								186,5		278,3					329,9					385,5						450,9					522,0					721,4				961,5
300								192,0		286,3					339,3					396,4						463,4					536,2					740,8				986,8
310								197,6		294,3					348,7					407,3						475,9					550,4					760,1				1012,0
320								203,1		302,3					358,1					418,1						488,3					564,6					779,4				1037,3
330								208,7		310,3					367,4					429,0						500,8					578,8					798,8				1062,5
340								214,2		318,2					376,8					439,9						513,3					593,0					818,1				1087,8
350								219,8		326,2					386,2					450,8						525,8					607,2					837,4				1113,0
360								225,3		334,2					395,6					461,6						538,3					621,4					856,8				1138,3
370								230,9		342,2					404,9					472,5						550,8					635,6					876,1				1163,5
380								236,4		350,2					414,3					483,4						563,2					649,9					895,4				1188,8
390								242,0		358,2					423,7					494,3						575,7					664,1					914,8				1214,1
400								247,5		366,2					433,1					505,1						588,2					678,3					934,1				1239,3
410								253,1		374,2					442,5					516,0						600,7					692,5					953,4				1264,6
420								258,6		382,2					451,8					526,9						613,2					706,7					972,8				1289,8
430								264,2		390,2					461,2					537,8						625,7					720,9					992,1				1315,1
440								269,7		398,2					470,6					548,7						638,2					735,1					1011,4				1340,3
450								275,3		406,1					480,0					559,5						650,6					749,3					1030,8				1365,6
460								280,8		414,1					489,3					570,4						663,1					763,5					1050,1				1390,8
470								286,4		422,1					498,7					581,3						675,6					777,7					1069,5				1416,1
480								291,9		430,1					508,1					592,2						688,1					791,9					1088,8				1441,3
490								297,5		438,1					517,5					603,0						700,6					806,1					1108,1				1466,6
500								303,0		446,1					526,9					613,9						713,1					820,3					1127,5				1491,8
+ 2 HV-washers								12,6		21,2					26,1					41,4						50,0					58,8					94,4				109,4
+ 1 HV-nut								26,2		46,0					69,9					81,8						97,2					116,9					170,4				231,7
Σ								38,8		67,2					96,0					123,2						147,2					175,7					264,8				341,1

Dast Guideline 021 Bolt & Nut Weight Chart | Hot Dip Galvanised Hv Bolt & Nut Weight Count Chart | Bigger Diameter Bolt Weight Count Chart | Large Diameter Bolt & Nut Weight Count Chart
